Featuring a 24-pin connector, the HR Pro Series 26 AWG DVI-D Dual-Link Cable from Comprehensive is designed to support high-speed video transmission between computers, video/data projectors, and other display devices. A single DVI-D male connection on each side makes for easy installation. Once connected, this cable supports video in resolutions up to 2048 x 1536 at 60 Hz or 1920 x 1080 at 85 Hz, and features a bandwidth speed up to 10.2 Gbps. Double-shielded 26 AWG construction helps eliminate interference while meeting all DDWG specifications.
Description
Additional information
| Weight | 3.2 lbs |
|---|---|
| Dimensions | 9.7 × 9.3 × 2.4 in |
| Connector 1 | 1 x DVI-D Dual Link Male |
| Connector 2 | 1 x DVI-D Dual Link Male |
| Cable Length | 25' / 7.62 m |
| Conductor Material | Copper |
| Jacket Type | Polyvinyl Chloride (PVC) |
| Shielding | 100% Aluminum-Mylar Braid |
| Maximum Resolution Support | 1920 x 1080 at 85 Hz |
| Wire Gauge | 26 AWG |
| Certifications | HDCP, RoHS, VW-1, as per Manufacturer |
| Operating Temperature | 167°F / 75°C |
