Description
Comprehensive CAT5e 350 MHz Shielded LAN Cable
Enhance your network infrastructure with the Comprehensive CAT5e 350 MHz Shielded LAN Cable, designed for high-performance and reliability in environments with high electromagnetic interference (EMI) and radio-frequency interference (RFI). This 1,000-foot, black cable is engineered to exceed CAT5e standards, ensuring fast and stable connections for your home, office, or campus network.
Key Features
- Shielded Twisted Pairs: 4 shielded twisted pairs minimize crosstalk and electromagnetic interference.
- Solid 24 AWG Conductors: Provides reliable signal transmission and durability.
- 350 MHz Bandwidth: Exceeds the CAT5e 100 MHz standard for superior performance.
- PVC Jacket: Durable and flexible for various installation environments.
- Foot-Marked and Pull Box Packaging: Simplifies installation and management.
Benefits
This CAT5e shielded LAN cable is ideal for network wiring in diverse settings, from residential to commercial and campus environments. Its high bandwidth and shielding ensure that your network operates at peak efficiency, even in areas with significant EMI/RFI. By exceeding the TIA/EIA-568 and 570 standards, this cable guarantees compatibility and performance for your network infrastructure.
Upgrade your network with the Comprehensive CAT5e 350 MHz Shielded LAN Cable for a faster, more reliable connection.
Additional information
| Weight | 26.35 lbs |
|---|---|
| Dimensions | 14.25 × 14.25 × 8.5 in |
| Conductors | 4 x twisted pair, 24 AWG, shielded bare copper solid cable |
| Bandwidth | Supports voice/data/video distribution applications up to 350 MHz |
| Standards | Meets all CAT5e TIA/EIA standards, Verified to EIA/TIA 568B.2 |
| Conductor DC Resistance | 89 Ω/km (maximum) |
| Insulation Resistance | 100 Ω/km (minimum) |
| Outer Diameter | 0.24" (6.10 mm) |
| UL Rating | CMR |
| Jacket | PVC |
| Compliance | RoHS |
| Electrical | Temperature rating: 167°F (75°C)<br>Spark test: 2, 000 VAC/0.15 sec minimum<br> Dielectric strength: AC 750 V/sec minimum<br>Insulation resistance: PE: 500 VDC 1500 MW/100 m minimum at 68°F (20°C) |
| Capacitance | Mutual capacitance: 5.6 nF/100 m, maximum<br>Pair to ground Unbalance: 330 pF/100 m, maximum<br>DC Resistance: 9.38 Ω/100 m at 68°F (20°C) maximum<br>DC Resistance Unbalance: 5%, maximum<br>Impedance: 100 ± 15 Ω at 100 to 350 MHz |
| Length | 1, 000' (305 m) |
